Siemens 6RA70 Series User Manual

7-10 Siemens Energy & Automation
SIMOREG DC Master Base Drive Panel Operating Instructions
H1 H2 H3
H4
230 V
BASE DRIVE PANEL, 510 AMPS, 1 & 4 QUAD
TRANSFORMER
1CFU
3CFU
2CFU
J2
J1
85 82
84 83
3U1 3W1
1U1 1V1 1W1
ARMATURE
SUPPLY
FIELD
SUPPLY
1C1 1D1
3C 3D
XR
5U1 5W1 5N1
PWR
SUPPLY
PWR
SUPPLY
K1
J4
88
89
MREC
L2L1
XF
X2
J3
86
87
M
ENSP
M AUX
M
EN
38
EN
XRXPXP
109 110
XP
XF1-2
XF1-1
XF2-2
XF2-1
X171
CTB
CONTROL
350VA
A1-TRC-Q0C-287
3.5A,600V
1CFU-2CFU
A1-FUF-AFA-014
2A,250V
3CFU
A1-FUF-DKA-GBV
500A,500V
A1-FUF-00D-030
600A,700V
A1-FUF-00E-031
4Q UNITS
ONLY
ENABLE RELAY
3RH1122-1AP60
SUPPRESSOR
3RT1916-1BD00
4N14U1
RECT. BR
A1-116-002-001
DC CONTACTOR
A1-CRD-CAC-010
FAN
SUPPLY
106 105
XS
E-STOP
XS
EN
90
91
ENABLE
94 93
J5
CTB
F(+)
F(-)
POWER MODULE
CATALOG NO. 6RA7087-6FS22-0Z+X01, (1-QUAD)
CATALOG NO. 6RA7087-6FV62-0Z+X01, (4-QUAD)
1CTR
1PFU 2PFU 3PFU
4PFU
1FSFU 2FSFU
40A,700V
A1-FUF-END-C40
460 VAC
L2
L1
L3
2 - #500 MCM,75 C
TORQUE TO
375 INCH- LBS
MAIN DISCONNECT AND
BRANCH CIRCUIT
PROTECTION SIZED
PER N.E.C.
CUSTOMER SUPPLIED
IF APPLICABLE
80 81
#8 AWG, 60 C
TORQUE TO
7 INCH- LBS
A1
A2
MOTOR = 500 VOLTS DC
F.L.A. = 510 AMPS DC
2 - #500 MCM, 75 C
TORQUE TO
375 INCH- LBS
