SIMOREG DC Master Base Drive Panel Operating Instructions
Sheet 13 Status Word 2
87564321
6RA70 DC MASTER
SIMPLIFIED BLOCK DIAGRAM
(ALL AVAILABLE FUNCTIONS ARE NOT SHOWN ON SIMPLIFIED BLOCK DIAGRAM)
13
1
1
1
1
1
1
1
1
1
1
19 18 17 Bit16
20
21
22
23
Bit2425262728293031
Bit 16
Bit 17
Bit 18
Bit 19
Bit 20
Bit 21
Bit 22
Bit 23
Bit 24
Bit 26
Bit 27
Bit 28
Bit 29
Bit 30
Bit 31
Bit No.
r653
K0033
B0136
B0137
B0138
B0139
B0140
B0141
B0142
B0143
B0144
B0145
B0146
B0147
B0148
B0149
B0150
B0151
B0152
B0153
B0156
B0157
Bit 25
Status word 2
Meaning
Status word 2
from sheet "Signals"
from alarm processing
from fault processing
from alarm processing
from alarm processing
from alarm processing
from fault processing
from sequencing control
from sequencing control
from sequencing control
Spare
0 = Overspeed
1 = No overspeed
1 = External fault 1 active
0 = No extern fault 1 active
1 = External fault 2 acrive
0 = No external fault 2 active
1 = External alarm active
0 = No external alarm active
1 = Motor overtemperature alarm active
0 = No motor overtemperature alarm active
1 = Motor overtemperature fault active
0 = No motor overtemperature fault active
spare
1 = Motor locked fault active
0 = No motor locked fault active
spare
spare
spare
Spare
1 = Power section overload alarm active
0 = No overload alarm active
1 = Power section overtemperature fault active
0 = No overtemperature faultactive
1 = Power section overtemperature alarm active
0 = No overtemperature alarm active
Display of status word 2 (r653)
on 7-segment display
To Next Page
