Siemens 6RA70 Series User Manual

SIEMENS Energy & Automation 10-13
SIMOREG DC Master Base Drive Panel Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
r059 Display of operating state
Meaning as for r000
0.0 to 14.5
0.1
Ind: None
Type: O2
P052 = 3
10.4 Definition of SIMOREG DC MASTER converter
r060
(G101)
Software version
Converter software release
i001: CUD
i002: Slot D (board location 2)
i003: Slot E (board location 2)
i004: Slot F (board location 3)
i005: Slot G (board location 3)
0.0 to 9.9
0.1
Ind: 5
Type: O2
P052 = 3
r061
(G101)
Creation date of software
i001: Year
i002: Month
i003: Day
i004: Hour
i005: Minute
Ind: 5
Type: O2
P052 = 3
r062
(G101)
Checksum
i001: Converter firmware checksum
i002: Boot sector checksum
Ind: 2
Type: L2
P052 = 3
r063
(G101)
Board code
Identification code of boards mounted in locations 1 to 3 of electronics box.
CUDx
FD
EG
132
Arrangement of
board locations 1 to 3
and slots D to G in
electronics box
i001: Board in location 1
71: CUD1
72: CUD1 + CUD2
i002: Board in slot D (upper slot of location 2)
111: Pulse encoder board (SBP) [SW 1.8 and later]
131 to 139: Technology board
141 to 149: Communications board
151, 152, 161: Special board (EB1, EB2, SLB)
i003: Board in slot E (lower slot of location 2)
111: Pulse encoder board (SBP) [SW 1.8 and later]
131 to 139: Technology board
141 to 149: Communications board
151, 152, 161: Special board (EB1, EB2, SLB)
i004: Board in slot F (upper slot of location 3)
111: Pulse encoder board (SBP) [SW 1.8 and later]
141 to 149: Communications board
151, 152, 161: Special board (EB1, EB2, SLB)
i005: Board in slot G (lower slot of location 3)
111: Pulse encoder board (SBP) [SW 1.8 and later]
141 to 149: Communications board
151, 152, 161: Special board (EB1, EB2, SLB)
Ind: 5
Type: O2
P052 = 3
