Siemens 6RA70 Series User Manual

6-8 Siemens Energy & Automation
SIMOREG DC Master Base Drive Panel Operating Instructions
Dimensions are mm (inches)
P
X300
SIEMENS 6RA70
L1 L2
L3 A1
A2
430 AMP BASE DRIVE PANEL, (1 & 4Q)
ADDITIONAL CLEARANCE
REQ'D FROM CONTACTOR
ARC CHUTE TO ANY
GROUNDED METAL
35
(1.4)
TERMINALS 80 - 94
334 (13.1)
520 (20.5)
550 (21.6)
15
(0.6)
20
(0.8)
1200
(47.2)
880
(34.6)
280
(11.0)
FUSE NOT SUPPLIED
ON 1-QUAD UNITS
GROUND TERMINALMOUNTING HOLES FOR M10,
(.375"), SCREWS, 6-PLACES
348 (13.7)
