Siemens 6RA70 Series User Manual

Siemens Energy & Automation 6-5
SIMOREG DC Master Base Drive Panel Operating Instructions
Dimensions are mm (inches)
SIEMENS
P
X300
6RA70
L1 L2 L3 A1
A2
326(12.8)
TERMINALS 80 - 92
266(10.5)
290(11.4)
12
(0.45)
10
(0.4)
980
(38.6)
960
(37.8)
140 AMP BASE DRIVE PANEL, (1 & 4Q)
GROUND
TERMINAL
MOUNTING HOLES FOR M8,
(.312"), SCREWS, 4-PLACES
FUSE NOT
SUPPLIED
ON 1-QUAD
UNITS
NOTE, IMPORTANT:
ALLOW AT LEAST 100 MILLIMETERS, (4"), OF CLEARANCE ABOVE AND BELOW THE UNIT
TO ENSURE UNRESTRICTED AIR FLOW. ADDITIONAL CLEARANCE MAY BE REQUIRED TO ALLOW FOR WIRE
OR CABLE ENTRY/EXIT AND BENDING. REFER TO APPLICABLE CODES FOR FURTHER INFORMATION.

Siemens 6RA70 Series Specifications

General

Cooling Method	Forced air cooling
Operating Modes	Speed control, torque control, current control
Output Current	15 A to 2000 A (models vary)
Communication Interfaces	PROFIBUS, RS232, RS485
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Enclosure Rating	IP00
Input Voltage	3-phase, 380-500V AC
