Siemens 6RA70 Series User Manual

7-8 Siemens Energy & Automation
SIMOREG DC Master Base Drive Panel Operating Instructions
H1 H2 H3 H4
230 V
M
BASE DRIVE PANEL, 255 AMPS, 1 & 4 QUAD
TRANSFORMER
1PFU 2PFU 3PFU
1CFU
3CFU
2CFU
J2
J1
85 82
84 83
POWER MODULE
3U1 3W1 1U1 1V1 1W1
ARMATURE
SUPPLY
FIELD
SUPPLY
1C13C
3D
4PFU
XR
5U1 5W1 5N1
PWR
SUPPLY
PWR
SUPPLY
K1
J4
88
89
1SP
L2L1
XF
X2
J3
86
87
M
XP XP
109
XR
110
XP XF1-2 XF1-1
XF2-2
XF2-1
CTB
250A,500V
A1-FUF-00D-023
300A,700V
A1-FUF-00E-025
1D1
4Q UNITS
ONLY
350VA
A1-TRC-Q0C-287
3.5A,600V
A1-FUF-AFA-014
1CFU - 2CFU
2A,250V
A1-FUF-DKA-GBV
3CFU
CONTROL
CONTACTOR
3TF5322-0AP6
SUPPRESSOR
3TX7462-3J
MAIN
F(+)
F(-)
CATALOG NO. 6RA7082-6FS22-0Z+X01, (1-QUAD)
CATALOG NO. 6RA7082-6FV62-0Z+X01, (4-QUAD)
1CTR
80
81
#10 AWG, 60 C
TORQUE TO
5 INCH- LBS
A1
A2
MOTOR = 500 VOLTS DC
F.L.A. = 255 AMPS DC
460 VAC
L2
L1
L3
2 - #250 MCM,75 C
TORQUE TO
275 INCH- LBS
MAIN DISCONNECT AND
BRANCH CIRCUIT
PROTECTION SIZED
PER N.E.C.
CUSTOMER SUPPLIED
IF APPLICABLE
2 - #250 MCM, 75 C
TORQUE TO
275 INCH- LBS
106 105
XS
E-STOP
XS
MAUX
90 91
1FSFU 2FSFU
40A,700V
A1-FUF-END-C40

Siemens 6RA70 Series Specifications

General

Cooling Method	Forced air cooling
Operating Modes	Speed control, torque control, current control
Output Current	15 A to 2000 A (models vary)
Communication Interfaces	PROFIBUS, RS232, RS485
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Enclosure Rating	IP00
Input Voltage	3-phase, 380-500V AC
