Siemens 6RA70 Series - Configuring of Closed-Loop Control; P595 Source for Actual Value of Overspeed Signal”; P597 Source for Actual Value of “Nset = Nact Signal 2”; P600 Source for Gating Unit Input (Armature)

SIEMENS Energy & Automation 10-59
SIMOREG DC Master Base Drive Panel Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
P592
*
(G187)
Source for actual value of "n < n
comp.
signal”
n < n
comp.
signal:
Selection of connector to be injected as input quantity (n) for the n < n
comp.
signal.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=167
Type: L2
P052 = 3
P051 = 40
Offline
P593
*
(G187)
Source for actual value of “n < n
min
signal”
n < n
min
signal:
Selection of connector to be injected as input quantity (n) for the n < n
min
signal.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=167
Type: L2
P052 = 3
P051 = 40
Offline
P594
*
(G188)
Source for input quantity of "Polarity signal”
Polarity signal of speed setpoint:
Selection of connector to be injected as input quantity "n
set
" for the polarity
signal of the speed setpoint.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=170
Type: L2
P052 = 3
P051 = 40
Offline
P595
*
(G188)
Source for actual value of "Overspeed signal”
Overspeed signal:
Selection of connector to be injected as input quantity "n
act
" for the
overspeed signal.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=167
Type: L2
P052 = 3
P051 = 40
Offline
P596
*
(G187)
Source for setpoint of "nset = nact signal 2” [SW 1.9 and later]
Setpoint/actual value deviation signal:
Selection of connector to be injected as input quantity "n
set
" for the
setpoint/actual value deviation signal.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=174
Type: L2
P052 = 3
P051 = 40
off-line
P597
*
(G187)
Source for actual value of “nset = nact signal 2” [SW 1.9 and later]
Setpoint/actual value deviation signal:
Selection of connector to be injected as input quantity "n
act
" for the
setpoint/actual value deviation signal.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=167
Type: L2
P052 = 3
P051 = 40
off-line
10.34 Configuring of closed-loop control
Setting values for configuring of torque shell
P600
*
(G163)
Source for gating unit input (armature)
i001 to i004:
Selects which connectors are applied as the gating unit input
(armature). All four values are added.
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=
i001: 102
i002: 0
i003: 0
i004: 0
Typ: L2
P052 = 3
P051 = 40
off-line
