Siemens 6RA70 Series - Control Word 2

SIEMENS Energy & Automation 10-69
SIMOREG DC Master Base Drive Panel Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
P666
*
BDS
(G180)
2nd source for control word 1, bit7
(0
→1 transition=acknowledge; ORed with 1
st
and 3
rd
sources for bit7)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P667
*
BDS
(G180)
3rd source for control word 1, bit7
(0
→1 transition=acknowledge; ORed with 1
st
and 2
nd
sources for bit7)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P668
*
BDS
(G180)
Source for control word 1, bit8
(1=inching bit0)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P669
*
BDS
(G180)
Source for control word 1, bit9
(1=inching bit1)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P671
*
BDS
(G180)
Source for control word 1, bit11
(0=pos. direction of rotation disabled, 1=pos. direction of rotation enabled)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P672
*
BDS
(G180)
Source for control word 1, bit12
(0= neg. direction of rotation disabled, 1= neg. direction of rotation enabled)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P673
*
BDS
(G180)
Source for control word 1, bit13
(1=raise motorized potentiometer)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P674
*
BDS
(G180)
Source for control word 1, bit14
(1=lower motorized potentiometer)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P675
*
BDS
(G180)
Source for control word 1, bit15
(0=external fault, 1=no external fault)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
Control word 2
P676
*
BDS
(G181)
Source for control word 2, bit16
(select function data set bit 0)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P677
*
BDS
(G181)
Source for control word 2, bit17
(select function data set bit 1)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P680
*
BDS
(G181)
Source for control word 2, bit20
(select fixed setpoint 0)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P681
*
BDS
(G181)
Source for control word 2, bit21
(select fixed setpoint 1)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P684
*
BDS
(G181)
Source for control word 2, bit24
(0=n controller speed droop disabled, 1=enabled)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P685
*
BDS
(G181)
Source for control word 2, bit25
(0=n controller disabled, 1=n controller enabled)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P686
*
BDS
(G181)
Source for control word 2, bit26
(0=external fault 2, 1=no external fault 2)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P687
*
BDS
(G181)
Source for control word 2, bit27
(0=master drive, speed control, 1=slave drive, torque control)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P688
*
BDS
(G181)
Source for control word 2, bit28
(0=external alarm 1, 1=no external alarm 1)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
