SIMOREG DC Master Base Drive Panel Operating Instructions
3.4 Spare Parts
Printed Circuit Boards
DESCRIPTION WHERE USED
US Rating 460V
PART
NUMBER
RECOM
SPARE
Microprocessor board CUD1
(C98 043-A7001-L1)
All Ratings 6RY1703-0AA00 1
Power Interface board 1Q (85 to 575 VAC)
(C98 043-A7002-L1)
All 1Q Ratings 6RY1703-0DA01 1
Power Interface board 4Q (85 to 575 VAC)
(C98 043-A7002-L4)
All 4Q Ratings 6RY1703-0DA02 1
PMU Operator Panel (C98 043-A7005-L1) All Ratings 6RY1704-0AA00 -
Field Supply board (C98 043-A7014-L1) 30 to 100 Amp 6RY1703-0CA03 1
Field Supply board (C98 043-A7014-L2) 140 to 510 Amp 6RY1703-0CA01 1
Field Supply board (C98 043-A7004-L1) 850 to 1660 Amp 6RY1703-0EA01 1
Field Supply board (C98 043-A7004-L3) 1680 Amp 6RY1703-0EA03 1
Snubber board (C98 043-A7007-L4) 60 to 100 Amp 6RY1703-0FA04
Snubber board (C98 043-A7007-L6) 30, 140 & 210 Amp 6RY1703-0FA11 -
Snubber board (C98 043-A7011-L6) 255 & 430 Amp 6RY1703-0FA10 -
Snubber boards (C98 043-A7011-L1) 510 & 850 Amp 6RY1703-0FA06 -
Main Power Section Connector board
(C98 043-A7010-L2)
15 Amp (1Q, 4Q) 6RY1703-0CA04 1
Fuse for Power Supply, 1 amp F1, F2
Mounted on Power Interface board
15 – 1680 Amp 6RY1702-0BA00 2
Cables
DESCRIPTION WHERE USED
US Rating 460V
PART
NUMBER
RECOM
SPARE
Ribbon Cable 20 pole X102 15 amp 6RY1707-0AA00
Ribbon Cable 64 pole X101 15 to 430 amp 6RY1707-0AA01
-
Ribbon Cable 20 pole X102 30 to 210 amp 6RY1707-0AA02 -
Ribbon Cable 20 pole X102 255 & 430 amp 6RY1707-0AA03 -
Ribbon Cable 20 pole X102 510 amp 6RY1707-0AA12 -
Ribbon Cable 64 pole X101 510 amp 6RY1707-0AA05 -
Ribbon Cable 20 pole X102 850 to 1680 amp 6RY1707-0AA06 -
Ribbon Cable 64 pole X101 850 to 1680 amp 6RY1707-0AA07 -
