Siemens 6RA70 Series User Manual

3-8 Siemens Energy & Automation
SIMOREG DC Master Base Drive Panel Operating Instructions
Field Converter AC Line Fuses (1 & 2FSFU)
DESCRIPTION WHERE USED
US Rating 460V
PART NUMBER RECOM
SPARE
20 amp, 700 volt 60 to 210 amp A1-FUF-END-C20 2
40 amp, 700 volt 255 to 850 amp A1-FUF-END-C40 2
50 amp, 700 volt 1180 to 1660 amp A1-FUF-END-C50 2
125 amp, 600 volt 1680 amp A1-FUF-HHA-024 2
Control Transformer Primary Fuses (1CFU, 2CFU)
DESCRIPTION WHERE USED
US Rating 460V
PART NUMBER RECOM
SPARE
1.25 amp, 600 volt, Class "CC" 15 to 100 amp A1-FUF-AFA-006 2
2.5 amp, 600 volt, Class "CC" 140 & 210 amp
1180, 1660 &
1680 amp
A1-FUF-AFA-011 2
3.5 amp, 600 volt, Class "CC" 255 to 510 amp
850 amp, (460
volt input only)
A1-FUF-AFA-014 2
5 amp, 600 volt, Class "CC" 1180, 1660 &
1680 amp
(
4CFU, 5CFU,
6CFU, 7CFU)
A1-FUF-AFA-016 4
Control Transformer Secondary Fuse (3CFU)
DESCRIPTION WHERE USED
US Rating 460V
PART NUMBER RECOM
SPARE
0.75 amp, 250 volt, Type MDL 15 to 100 amp A1-FUF-DKA-GBF 2
1.5 amp, 250 volt, Type MDL 140 & 210 amp
1180,1660 &
1680 amp
A1-FUF-DKA-GBP 2
2 amp, 250 volt, Type MDL 255 to 510 amp A1-FUF-DKA-GBV 2
6.25 amp, 250 volt, Type MDL 850 amp A1-FUF-DKA-GCM 2
