SIEMENS Energy & Automation 10-49
SIMOREG DC Master Base Drive Panel Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
P453
*
BDS
(G145)
Source for "Enable zero marker counter" command [SW 1.9 and later]
Selection of binector to control enabling of the zero marker counter
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
off-line
10.23 Connector selector switches
(see also Section 8, Function Diagram Sheet G124 of Operating Instructions 6RX1700-0AD**)
P455
*
(G124)
Source for inputs of connector selector switch 1 [SW 1.9 and later]
Selection of connectors for the input signals for connector selector switch 1.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
P456
*
(G124)
Source for control of connector selector switch 1 [SW 1.9 and later]
Selection of binectors to control connector selector switch 1.
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
P457
*
(G124)
Source for inputs of connector selector switch 2 [SW 1.9 and later]
Selection of connectors for the input signals for connector selector switch 2.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
P458
*
(G124)
Source for control of connector selector switch 2 [SW 1.9 and later]
Selection of binectors to control connector selector switch 2.
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
10.24 Motorized potentiometer
(see also Section 8, Sheet G126 of Operating Instructions 6RX1700-0AD**)
P460
*
FDS
(G126)
Control word for motorized potentiometer ramp-function generator
0 The motorized potentiometer ramp generator is bypassed in
Automatic mode (same effect as for P462 and P463 = 0.01, i.e.
the generator output is made to follow the automatic setpoint
without delay)
1 Motorized potentiometer ramp generator is active in Manual and
Automatic modes
0 to 1
1
Ind: 4
FS=1
Type: O2
P052 = 3
P051 = 40
Offline
P461
*
FDS
(G126)
Source for setpoint in Automatic mode
Selection of the connector to be applied as the Automatic setpoint to the
ramp-function generator in the motorized potentiometer
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P462
FDS
(G126)
Ramp-up time for motorized potentiometer
0.01 to 300.00
[s]
0.01s
Ind: 4
FS=10.00
Type: O2
P052 = 3
P051 = 40
Online
P463
FDS
(G126)
Ramp-down time for motorized potentiometer
0.01 to 300.00
[s]
0.01s
Ind: 4
FS=10.00
Type: O2
P052 = 3
P051 = 40
Online
