Siemens 6RA70 Series User Manual

Siemens Energy & Automation 3-5
SIMOREG DC Master Base Drive Panel Operating Instructions
Fans/Blowers
DESCRIPTION WHERE USED
US Rating 460V
PART NUMBER RECOM
SPARE
FAN, 24 VDC
(C98130-A1256-C553)
140 & 210 amp 6RY1701-0AA07 2
FAN, 230 VAC, 1 Phase
(C98130-A7004-B130)
255, 430 & 510
amp
6RY1701-0AA11 1
FAN, 230 VAC, 1 Phase
(C98130-A7004-B330)
850 amp 6RY1701-0AA12 1
FAN, 460 VAC, 3 Phase
(C98 247-S1002-C25)
1180, 1660
&1680 amp
6RY1701-0AA04 1
Thyristors & Diodes
Armature Converter Thyristor Modules, (for 1-Quad Drives)
DESCRIPTION WHERE USED
US Rating 460V
PART NUMBER RECOM
SPARE
Dual Thyristor Module 15 amp 1Q 6RY1700-0AA16 3
Dual Thyristor Module 30 amp 1Q 6RY1700-0AA17 3
Dual Thyristor Module 60 amp 1Q 6RY1700-0AA18 3
Dual Thyristor Module 100 amp 1Q 6RY1700-0AA11 3
Dual Thyristor Module 140 amp 1Q 6RY1700-0AA14 3
Dual Thyristor Module 210 amp 1Q 6SY7010-0AA02 3
Dual Thyristor Module 255 amp 1Q 6RY1700-0AA15 3
Dual Thyristor Module 430 amp 1Q 6SY7010-0AA05 3
Dual Thyristor Module 510 amp 1Q 6SY7010-0AA04 3
Dual Thyristor Module 850 amp 1Q 6RY1700-0AA04 3
Thyristor/Heatsink Assembly, Front
(C98 130-A1255-B510)
1180 amp 1Q 6RY1702-0CA15 2
Thyristor/Heatsink Assembly, Back
(C98 130-A1255-B511)
1180 amp 1Q 6RY1702-0CA16 2
Thyristor/Heatsink Assembly, Front
(C98 130-A1255-B520)
1660 amp 1Q 6RY1702-0CA17 2
Thyristor/Heatsink Assembly, Back
(C98 130-A1255-B521)
1660 amp 1Q 6RY1702-0CA18 2
Thyristor/Heatsink Assembly, Front 1680 amp 1Q 6RY1702-0CA30 2
Thyristor/Heatsink Assembly, Back 1680 amp 1Q 6RY1702-0CA31 2
