14 CLINITEK Status+ Analyzer Operator’s Guide
Introduction
Note If you want to connect the analyzer to a CLINITEK Status
connector, follow the instructions in the CLINITEK Status Connect
Unpacking and Installation Guide and the CLINITEK Status Connect
System Operator’s Guide, Section 6, System Configuration.
When you connect the analyzer to CLINITEK Status connector, you
can use wired (Ethernet) or wireless network connectivity, Quality
Control, increased security, bar-code scanning, and additional
features with the CLINITEK Status+ analyzer.
The CLINITEK Status connector provides standard wired and
wireless connectivity of the CLINITEK Status+ analyzer to your LAN,
LIS, HIS, or EMR. The connector also allows for centralized control
of all satellite Point of Care (POC) CLINITEK Status+ analyzers. For
details, see the CLINITEK Status Connect System Operator’s Guide.
Loading the Printer Paper
The analyzer uses ordinary thermal paper as provided, or label stock.
For more information about ordering supplies, see Appendix C,
Orderable Supplies.
To load the printer paper or label roll, perform the following steps:
1. With the back of the analyzer facing you, open the printer cover by
pulling up on the tab.
2. Open the paper roll compartment cover by pressing down on its
tab and pulling out the cover.
3. Lift the paper holding arm into the open, upright position.
4. Place the new paper roll into the printer paper compartment with
the paper unrolling from underneath and toward the
compartment wall.
5. Feed the paper up along the wall and through the printer until you
have approximately 10 cm (or 4 inches) of paper through the
printer.
CAUTION
Do not use batteries in the analyzer, if you attach the analyzer
to a CLINITEK Status connector. If you leave the batteries in
the battery compartment, the batteries may corrode.
