MODULARIS Uro Plus SPL1-130.840.02 Page 6 of 14 Siemens AG
Rev. 03 04.05 CS PS 24 Medical Solutions
2 - 6 LITHOSTAR MODULARIS Error List
Monitoring, E40 – E48 2
E40 Error Text: Cooling pump fuse defective.
Possible
cause/action:
Fuse F2 on board D3 o.k.?
E41 Error Text: Cooling pump M1 defective.
Possible
cause/action:
Motor M1 o.k.?
Circuit diagram J1048 – 13
Connection cable D3.X7 o.k.?
E42 Error Text: Coupling pump defective.
Possible
cause/action:
Motor M2 o.k.?
Circuit diagram J1048 – 13
Connection cable D3.X7 o.k.?
E43 Error Text: Fuse for coupling pump defective.
Possible
cause/action:
Fuse F3 on board D3 o.k.?
E44 Error Text: 5 volt power supply defective.
Possible
cause/action:
Replace board D3.
E45 Error Text: 18 volt power supply defective.
Possible
cause/action:
LED VCC18 on board D3 o.k. ?
Circuit diagram J1048 – 11
Connection cable D3.X8 o.k.?
Check the power supply for the pressure sensors!
E46 Error Text: 17 volt power supply defective
Possible
cause/action:
LED VCC17 on board D3 o.k. ?
Replace board D3.
E47 Error Text: Valve and card terminal fuse defective?
Possible
cause/action:
Short circuit?
Fuse F4 on board D3?
Circuit diagram J1048 – 13
Check valve (coupling circuit).
Check card terminal.
E48 Error Text: Reference for temperature sensors defective.
Possible
cause/action:
Replace temperature sensors.
Replace board D3.
