Service software 3 - 5
Siemens AG SPL1-130.840.02 Page 5 of 18 MODULARIS Uro Plus
Medical Solutions Rev. 03 04.05 CS PS 24
select option: h 3
• Press the "h" key to display the input menu.
select option: p 3
• Press the "p" key to display the following text:
The total number of shock waves released are displayed.
The counters for the shock head / capacitor / spark gap can be reset to zero.
Always perform this procedure when replacing one of these parts, i. e. the "spark gap"
counter must be reset to zero if the charging unit is replaced.
select option: d 3
Press the "d" key to display the following text
sensors (C-grade) Displays the temperature at the shock wave head in celsius.
The difference between both temperature values may not exceed a
maximum of 3° C.
HV (V) Displays the voltage at the high-voltage capacitor.
If there is no connection to the charging unit (i.e. fiber optic cable
removed), the value is 20460.
P-bellow (mV) Displays the pressure in the coupling bellows.
P-automatic selected and rinse ended:
Q 500 mV – 2000 mV o.k.
C-arm pot (mV) Current voltage at the potentiometer for the angulation motor.
US poti1/2 (mV) Current voltage at the potentiometer for the US applicator. Accepta-
ble deviation: 50.
When US localisation is not available the value is 9995.
=> P
number of pulses:
system: 3627
(1) shock head: 3627
(2) capacitor: 3627
(3) spark gap: 3627
select 1..3 to delete pulse counter, any other key to abort
please note values or save to file before deleting data !
Ö
D
'x'=exit
sensors HV P-bellow C-arm poti US poti1 US poti2
(C-grade) (V) (mV (mV) (mV) (mV)
24.15 23.97 20 756 5100 6300 6250
24.21 24.00 20 749 5100 6300 6250
