Siemens MODULARIS Uro Plus User Manual

5 - 1
Siemens AG SPL1-130.840.02 Page 1 of 8 MODULARIS Uro Plus
Medical Solutions Rev. 03 04.05 CS PS 24
Iso-center with X-Ray 5
LITHOSTAR MODULARIS to support arm serial number 0050
Adjustment procedure 5
Prerequisite: The potentiometer must be correctly adjusted on the motor.
If screws were loosened on the adjustment direction of the shock wave head they must be
tightened before checking the iso-center with X-ray.
The ball will jump when zooming, but this has no effect.
Before the iso-center can be checked or adjusted, the following
settings must be performed on the SIREMOBIL Iso-C:
1. Camera rotation to 0°.
2. Deselect image reverse vertical (LED is off).
3. Deselect image reverse horizontal (LED off).
NOTICE
I.I. replacement
X-ray tube / collimator
replacement
Shock wave head
replacement
Isocenter adjustment
-20° position
Isocenter check
+ 20° position
Isocenter adjustment
-20° position
Isocenter adjustment
0° position
Isocenter check
+ 20° position
Isocenter adjustment
-20° position
Isocenter adjustment
0° position
Isocenter check
+ 20° position
Isocenter adjustment
0° position
Concluding work
NOTICE
