MODULARIS Uro Plus SPL1-130.840.02 Page 12 of 14 Siemens AG
Rev. 03 04.05 CS PS 24 Medical Solutions
2 - 12 LITHOSTAR MODULARIS Error List
Ultrasound, E90 – E93 2
E90 Error Text:
Possible
cause/action: No connection from LITHOSTAR to SONOLINE
E91 Error Text:
Possible
cause/action:
Potentiometer skips.
Cable from potentiometer to board D3 ok?
Potentiometer defect?
E92 Error Text: The two potentiometers have different values.
Possible
cause/action:
Dampness on the potentiometer.
E93 Error Text: Erroneous US values.
Possible
cause/action:
C-MOS has lost values. Perform potentiometer adjustment
(Point "U" in the service menu).
Check default values (see SPL1-130.038.01...).
3
1
2
5
Value between 1 -3 and 2-5
must be identical.
Plug at US holder
