4 - 1
Siemens AG SPL1-130.840.02 Page 1 of 34 MODULARIS Uro Plus
Medical Solutions Rev. 03 04.05 CS PS 24
LITHOSTAR MODULARIS 4
LITHOSTAR MODULARIS Parts overview 4
Assembly
Comments on replacement
Function Item number
Shock wave head C
Shock wave head
C plus
16 11 008
70 41 358
Refer to description
Replace the water
Also replace the M1 pump head
Reset the counter to zero
SW head C is delivered without the coupling bel-
low, SW head C plus with coupling bellow
Coupling bellow C 47 78 705 The clamping strap 70 56 823 must be ordered
separately!
Coupl. bellow C plus 70 41 416 The clamping strap 70 61 013 must be ordered
separately
High voltage cable 11 81 523 Refer to description "cables in corrugated tubing"
High voltage connec-
tor
11 81 622 Refer to description
Charging unit 55 31 046 Refer to description
Charging unit HLS 11 58 000 Replaces charging unit with spark gap 55 31 046
Cooling unit 47 78 002 Refer to description
Fill in the "dates of start up" field.
Pump 47 73 847
70 41 101
Coupling pump; Refer to description
Cooling pump; Refer to description
Temperature sensor 55 31 277 Refer to description "cables in corrugated tubing"
Pressure sensor 55 31 243 Refer to description "cables in corrugated tubing"
Board D3 55 31 053 Refer to description
Battery for board D3 31 46 073
Control unit 55 31 129 No special instructions required
Perform a function test following replacement
Transformer and
board D1
55 31 111 Note jumpers for the line voltage
230 V: 3 -5, 200V: 2 - 6, 120 V:1 - 5 and 4 - 7,
100 V: 1 -6 and 2 - 7
Power supply board
D1
55 31 301 Check fuses
Angulation motor 55 31 392 Refer to description
MODULARIS sup-
port arm
55 31 020 Refer to description
Rotary joint lock 55 31 608 Refer to description
Potentiometer 70 50 433 Refer to description
SIREMOBIL switch 10 70 721 Refer to description
Iso-center phantom 47 78 754 Refer to description
