MODULARIS Uro Plus SPL1-130.840.02 Page 2 of 18 Siemens AG
Rev. 03 04.05 CS PS 24 Medical Solutions
3 - 2 Service software
German WINDOWS 95 / 98 / NT 3
Generate and switch on connection between Service PC and the D3.X9 (com 3 Service) board
in LITHOSTAR MODULARIS
Open the Hyper Terminal Program (located under "Windows" - "Zubehör")
Set switch S2 on board D3 to service
Click on Hypterm.exe
In the window " Beschreibung der Verbindung"
for the name: enter Litho / for the icon: select one and click OK
In the window "Rufnummer", select, com1 or com2 for the
connection, and click OK
Enter the following settings in the window:
Bits pro sekunde: 9600, Daten bits: 8
Parität: keine, Stopbits: 2 , Protokoll: kein and click OK
*Additional information: In order to save the information from LITHOSTAR MODULARIS, it is best to save
the desired file as a text file. Basic procedure: open Windows Explorer. Open the folder, e.g. Temp, then click on
the Datei menu and click "Neu / Textdatei". Enter the name for the text file.
In the window "Datei aufzeichnen" accept the file path indicated or
search for the desired file path with "Browse"... then click "Start"
Menu: Click on "Übertragung" and select "Text aufzeichnen"
Press the "H" key, the text is displayed
Perform the desired tasks (refer to pages 3-4 to 3-10)
Then in the "Übertragung" Menu , select "Text aufzeichnen" and select "Beenden"
In the "Datei" menu, click on exit
Enter the appropriate response to the other queries
Open the connection, e.g. Litho
Set switch S2 on board D3 back to normal and remove the connection cable
End
Save
the data to
drive a: or c:
No
Yes
First time
connection ?
NoYes
New
board?
Yes
Perform software download - page 3-13
