High voltage circuit, E60 – E67 2
LITHOSTAR MODULARIS Circuit diagram J1048 - 12.
E60 Error Text: Charging current too low during the charging process.
Possible
cause/action:
Check the line voltage!
Replace the charging / energy unit!
E61 Error Text: Overvoltage in the charging unit.
Possible
cause/action:
System OFF
- 10 minute pause -
System ON.
Replace the charging / energy unit!
E62 Error Text: Overtemperature in the charging unit.
Possible
cause/action:
Heat in the LITHO MODULARIS ?
System OFF
- 10 minute pause -
System ON.
Replace the charging / energy unit!
E63 Error Text: Capacitor defective in the charging / energy unit (out of tole-
rance).
Possible
cause/action:
Replace the charging / energy unit!
E64 Error Text: Default voltage not attained.
Current voltage after frequency converter (U
nom
) is greater than
selected voltage.
Possible
cause/action:
Check the fiber optic cable!
1
)
Replace the charging / energy unit!
E65 Error Text: Charging voltage too high during the charging process.
Possible
cause/action:
Replace the charging / energy unit!
E66 Error Text: Default voltage incorrect.
Possible
cause/action:
Check the fiber optic cable!
1
)
Replace the charging / energy unit!
E67 Error Text: No ignition of spark gap after trigger pulse (several times).
Possible
cause/action:
Check the fiber optic cable!
1
)
Replace the charging/ energy unit!
