MODULARIS Uro Plus SPL1-130.840.02 Page 10 of 18 Siemens AG
Rev. 03 04.05 CS PS 24 Medical Solutions
3 - 10 Service software
select option: a/b
• Press the "a" key to reduce the time by 50 ms
i.e. from 1200 ms to 1150 ms.
• Press the "b" key to increase the time by 50 ms
i.e. from 1200 ms to 1250 ms.
In case of problems decoupling the angulation motor, the motor follow-on time for relaxing
the coupling can be changed.
Time < 300 and > 5000 cannot be selected.
select option: i 3
• Press the "i" key to display the following text:
After pressing the "1" key and then the "h" key, display for "selection option i " reads "
now: installed".
select option: u 3
• Press the "u" key to display the following text:
• If the potentiometer has to be adjusted (i.e. after board D3 is replaced or after the D3
ultrasound addition), then perform the following procedure:
• Push the probe receiver all the way to the front so that the space between the probe and
the iso-center phantom is very small when the iso-center phantom is raised.
• After pressing the "j" key, after "actual value: established value (max. 500) appears.
You do not have to save changes
NOTICE
=> I
are you sure to install optionECG-trigger ?
press '1' to confirm, any other key to abort
=> U
---- submenu ultrasound adjust ----
to adjust marker position move applicator onto target
(see service instruction) and press key 'j'
actual value : _ _ _
change values for sector applicator - Press key 's'
change values for convex applicator - Press key 'c'
press key 'x' to exit
