MODULARIS Uro Plus SPL1-130.840.02 Page 10 of 14 Siemens AG
Rev. 03 04.05 CS PS 24 Medical Solutions
2 - 10 LITHOSTAR MODULARIS Error List
High voltage circuit, E75 – E78 2
E75 Error Text: Chip card terminal error (documented in error log only).
Possible
cause/action:
Check execution level for board D3:
AS 00 - 02: replace board D3.
AS 03 and higher: replace chip card reading device.
Wrong card or card incorrectly inserted.
E76 Error Text: Chip card expired
Possible
cause/action:
Insert a new card.
E77 Error Text: Chip card communication error
Possible
cause/action:
Check execution level for board D3:
AS 00 - 02: replace board D3.
AS 03 and higher: replace chip card reading device
Cable?
If the error recurs after replacing board D3, is plug X33 properly
connected?
E78 Error Text: Charging process too long.
Possible
cause/action:
Line voltage o.k.?
Replace the charging / energy unit!
E79 Error Text: Call Service
Possible
cause/action:
HV-cable ok?
Short circuit?
1
) Before replacing the charging / energy unit, check the fiber optic cable (LWL):
- Disconnect the fiber optic cable on both ends and check by holding it up to the light
or
- place it on the Clk (U5) of board D3 and check whether light is visible.
