MODULARIS Uro Plus SPL1-130.840.02 Page 4 of 34 Siemens AG
Rev. 03 04.05 CS PS 24 Medical Solutions
4 - 4 LITHOSTAR MODULARIS
• Open valve Y8(Fig. 10, 11),
i.e. switch the Y8 lever from horizontal = closed to vertical = open.
• Switch the system on.
• Set service switch S2 on board D3 to position 2 (service on).
• Select "service" on the control unit and then "cooling unit".
• Activate the corresponding key for "empty" on the control unit until no more water flows
out.
• Adjust service switch S2 on board D3 to position 1 (service off).
• Switch the system off.
• Remove the 2 Allen screws (U/Fig. 4) underneath the shock wave head.
• Remove the screw (SL/Fig. 7) with the protective conductor on the shock wave head.
• Wait at least 10 minutes after switching the system off. Then push the high-voltage
connector downward, until the openings (O/Fig. 7) are free.
• Loosen the Allen screws in the openings (O/Fig. 7) but do not remove them.
• Disconnect all the water hoses at both interfaces of the shock wave head.
• Remove the shock wave head toward the front.
There may be water remaining in the shock wave head.
NOTICE
