6 - 16 Iso-center with ultrasound
Checking the distance: Side (23b/Fig. 23)
• Press the key twice (cross "+1" is not needed for this measurement).
• Move the cross "+2" using the track ball onto the horizontal axis of the target line
(C/Fig. 23b).
• Press the key.
• Move the cross "+2" using the track ball horizontally into the center of the white area of
the isocenter phantom.
• If the center point of the white area (23b/Fig. 23) is not in the center
(permitted difference: +
0.5 mm from the center):
- Make a note of the value of D2 (with mathematical sign):
If the display of the ball (23b/Fig. 23) appears to the left of the isocenter, the correction
value must have a negative sign in front (to the right is a positive sign in front).
- Press the key.
- Press the "F4" key.
- Press the "5" key.
- Select "MUP" with the track ball.
- Press the key.
- Enter the password.
- Use the track ball to select the appropriate probe during image tilt.
- Press the key.
- Enter half the value of D2 (H/Fig. 23).
Example:(H/Fig. 23): D2 = 1,2 mm
⇒ Enter: -06 .
- Press the key.
- Press the key twice.
- Check the difference; if white area (23b/Fig. 23) is not in the center of the isocenter,
repeat the procedure.
• Press the key.
• After adjusting the mount for the ultrasound probe, attach it on the mount (7/Fig. 1).
For each probe, check whether the adjustment in this position is also okay. Do not make
any change to the image tilt adjustment.
• Following the check, store the parts in the appropriate transport cases.
German: Bildkippung Sektor
Bildkippung Array
French: Basculement d’image sondes sect.
Basculement d’image sondes conv.
English: Image Tilt Sector
Image Tilt Array
Spanish: Incl. imagen transd. sect mecanico
Inclinar imagen transductor curvo
