Expanding and assigning parameters to the device
7.6 Installing and removing drives
115
Maximum vibration load for drives in the respective installation location
Note
If the device is permanently installed, mounted on telescopic rails or operated as a tower, it
may only be exposed to the following vibration loads during operation.
The restrictions do not apply to the use of SSD.
Drives in drive cage type B
Drives in drive cage type B may be exposed to the following maximum vibration loads during
operation:
• 10 ... 58 Hz: 0.015 mm
• 58 Hz to 500 Hz: 2 m/s
2
Vib
rations must not exceed 500 Hz.
Possible drive configurations
You can implement the following drive configurations in the drive cage type B and on the
side panel of the device.
• Non-RAID system
• RAID1 system
• RAID5 system
• RAID1 system with hot spare drive
• RAID5 system with hot spare drive
Workstation SIMATIC IPC RW-545A
Operating Instructions, 08/2023, A5E52943278-AA
