A.3 System resources
171
0000 3000
0000 3FFF
4096
PCI Express Root Port
0000 4000
0000 403F
64
Intel® UHD Graphics 770
0000 FFF8
0000 FFFF
32
Intel® Active Management Technology -SOL
(COM5)
A.3.3 Interrupt assignments
The functions are assigned different interrupts, depending on the operating system. APIC
mode is used.
PCI / PCIe cards and the on-board PCI / PCIe devices require PCI interrupt lines. These interrupt
lines can be shared and are plug-and-play compatible. In other words, several devices can
share one interrupt. The IRQ is assigned automatically.
The table describes the assignment of the interrupts in the delivery state of the device.
IRQ number
Comment
IRQ (ACPI mode)
0
1
2
3
4
5
6
7
8
9
1
0
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
2
0
2
1
2
2
2
3
IRQ(ACPI
mode)
Host PCI IRQ Line
1
A
B
C
D
E
F
G
H
1
Function
System timer
X
Fixed
Communications Port
(COM1)
X
Fixed
Communications Port
(COM2)
X
Fixed
Communications Port
(COM3)
X
Fixed
Communications Port
(COM4)
X
Fixed
Intel® Serial IO GPIO
Host Controller -
INTC1056
X
Fixed
High Definition Audio
Controller
X
Can be
deactivated
X: Interrupt in APIC mode
1
: Host PCI-IRQ A to H is assigned to IRQ 16 to 23 permanently in APIC mode. A specific assignment cannot be forced.
A.3.4 Memory address assignments
The table describes the assignment of the memory addresses in the delivery state of the
device.
Address (hex)
Description of the basic function
from
to
000A 0000
000B FFFF
PCI Express Root Complex
000E 0000
000E 3FFF
PCI Express Root Complex
000E 4000
000E 7FFF
PCI Express Root Complex
