Siemens SIMATIC IPC RW-545A

141
Technical specifications
9
9.1 Applicability of technical specifications
Note
The following technical specifications only apply under the following conditions:
•
The device is in good working order.
•
The fan cover and filter mat are installed.
•
The device is closed.
•
The connected I/O devices meet the requirements for the respective area of application
(interference emission according to EN 61000-6-3 / IEC 61000-6-3, immunity to
interference according to EN 61000-6-2 / IEC 61000-6-2).
9.2 General technical specifications
See the note in "Applicability of technical specifications (Page 141)".
Article number
6AG4104 -6….-…. (for details, refer to the ordering documentation)
Dimensions
481.4 x 176.6 x 446.6 (W× H × D in mm)
Detailed dimensional specifications can be found in "Dimension drawing of the device
(Page 159)".
Weight
15 up to 23 kg; depending on the equipment
Supply voltage (U
N
; AC)
Power supply unit 550 W; AC:
• 100 V to 240 V AC (-15%; +10%)
Power supply unit 850 W; (AC):
• 100 V to 240 V AC (-10%; +10%)
Power supply unit 700 W (2 modules, each 700 W, redundant; AC):
• 2 × 100 V to 240 V (-15%; +10%)
Transient overvoltages
Device is designed for connection to supply with overvoltage category II
(Transient overvoltages up to 2500 V)
Input current
Power supply unit 550 W:
• Continuous current at 100 V: ≤ 8 A
• Continuous current at 230 V: ≤ 4 A
• At startup ≤ 80 A for 3.6 ms
Workstation SIMATIC IPC RW-545A
Operating Instructions, 08/2023, A5E52943278-AA
