Technical specifications
9.6 Technical specifications of the drives
149
9.6 Technical specifications of the drives
See the note in "Applicability of technical specifications (Page 141)".
Information on the drives is available in your order documents.
Maximum
number
• 4 SATA ports: HDD / SSD
• See: "Installation options for drives with drive cage type A (Page 104)" and "Installation options for
drives with drive cage type B (Page 114)"
HDD
HDD types (Native Command Queuing is supported):
• 3.5" SATA; 6 GB/s; 7200 rpm; 2000 GB
• 3.5" SATA, Enterprise, 6 GB/s; 7200 rpm; 2000 GB and 4000 GB
SSD
SSD types (flash memory):
• 2.5" SATA, 6 GB/s; 480 GB
• 2.5" SATA, 6 GB/s; 960 GB
M.2 NVMe SSD
2x M.2-2280 Key M, PCIe Gen4 x4 *; 512 GB and 1024 GB; length: Max. 80 mm
* You can find the maximum theoretical data rate of a PCIe lane in the technical specifications of the device
9.7 Technical specifications of the motherboard
9.7.1 General technical specifications of the motherboard
See the note in "Applicability of technical specifications (Page 141)".
Chipset
Intel® R680E PCH
Processor
• Core i3-12100E
4C(4P)/8T, 3.2 (4.2) GHz, 12 MB Cache
• Core i5-12500E
6C(4P)/12T, 2.9 (4.5) GHz, 18 MB Cache
• Core i7-12700E
12C(8P+4E)/20T, 2.1 (4.8) GHz, 25 MB Cache
• Core i9-12900E
16C(8P+8E)/24T, 2.3 (5.0) GHz, 30 MB Cache
RAID (onboard)
Intel
®
PCH with Intel
®
Rapid Storage Technology
Slots for memory modules
4 x DIMM sockets for DDR5 4400 MHz, expandable to 128 GB
Main memory
8 to 128 GB, DDR5
See also
Technical specifications of the expansion card slots (Page 150)
