Operating the device
6.4 Onboard RAID system
82
6.4.3.3 Integrating a new drive into an onboard RAID system
The onboard RAID system is configured in the delivery state so that a new drive must be
integrated manually when a defective drive was replaced.
You can also configure the onboard RAID system in such a way that the new drive is
automatically mounted when the defective drive is replaced.
Onboard RAID systems with a hot-spare drive are configured so that the hot-spare drive is
automatically integrated in the event of an error.
Configure "Automatic integration of a new drive" (before replacing a defective drive)
If a new drive is automatically integrated, the new drive is not checked for partition
information or existing data.
All partitions and data of the new drive are deleted without warning.
• Insert only a brand new drive or a drive that is configured as a replacement drive.
1. Select "Start" > "Intel® Optane™ Memory and Storage Management".
2. Select the "Manage" menu.
3. Select "Settings".
4. Set the "Auto-rebuild on hot plug" option to "Enabled".
Configure the mounted drive under "Create Raid Volume".
Configure "Manual integration of a new drive" (before replacing a defective drive)
The onboard RAID system is configured in the delivery state so that a new drive must be
integrated manually when a defective drive was replaced.
You can configure the manual integration of the drive or check the settings yourself.
To do this, disable the function to automatically mount a new drive.
1. Select "Start" > "Intel® Optane™ Memory and Storage Management".
2. Select the "Manage" menu.
3. Select "Settings".
4. Set the "Auto-rebuild on hot plug" option to "Disabled".
Configure the mounted drive under "Create Raid Volume".
Mount new drive during operation in the onboard RAID system (after an error has occurred)
Requirement
The system is configured to mount new drives manually (not automatically), see above.
Workstation SIMATIC IPC RW-545A Operating
Instructions, 08/2023, A5E52943278-AA
