Siemens SIMATIC IPC RW-545A

Technical specifications
9.8 Technical specifications of graphic
152
9.8 Technical specifications of graphic
See the note in "Applicability of technical specifications (Page 141)".
Technical specifications of the integrated graphics interfaces
Graphics controller
• Intel® UHD Graphics 730
integrated in processor:
– Core i3-12100E
• Intel® UHD Graphics 770
integrated in processor:
– Core i5-12500E
– Core i7-12700E
– Core i9-12900E
Graphics memory
Dynamic Video Memory Technology,
uses at least 64 MB in main memory
Resolutions/frequencies/colors
• DVI: 1920 × 1200 at 60 Hz; 32-bit color depth
• DisplayPort: 4096 × 2304 at 60 Hz; 32-bit color depth
• VGA (via DP-VGA adapter): 2560 × 1600 at 60 Hz; 32-bit color depth
Technical specifications of the NVIDIA T400 graphics card
You can find information on connection options for monitors with adapters under "Hardware
accessories (Page 32)
"
.
Type:
NVIDIA T400, 4 GB graphics memory
PCIe x16; Triple Head
Maximum resolution
without adapter:
• 3x Mini DisplayPort
4096 x 2160 at 60 Hz; 32-bit color depth
• 1x Mini DisplayPort
5120 × 2880 at 60 Hz; 32-bit color depth
Maximum resolution
with adapter:
• up to 3x DisplayPort:
4096 x 2160 at 60 Hz; 32-bit color depth
• 1x DisplayPort:
5120 × 2880 at 60 Hz; 32-bit color depth
• up to 3x DVI:
1920 × 1200 at 60 Hz; 32-bit color depth
• up to 3x VGA:
2048 × 1536 at 60 Hz; 32-bit color depth
Workstation SIMATIC IPC
RW-545A Operating
Instructions, 08/2023, A5E52943278-AA
