Markings and symbols
C
C.1 Overview
The following tables show all the symbols which may be found on your SIMATIC industrial PC,
SIMATIC industrial monitor or SIMATIC Field PG in addition to the symbols which are
explained in the operating instructions.
The symbols on your device may vary in some details from the symbols shown in the
following tables.
C.2 Symbols for safe use and disposal
Symbol
Meaning
Symbol
Meaning
Warning, observe the supplied
documentation.
Lock is closed
Attention, radio equipment
Lock is open
Disconnect the power plug before
opening
Opening for Kensington lock
Attention ESD (Electrostatic sensitive
device)
Warning of hot surface
Disposal information, observe the
local regulations.
C.3 Symbols for operator controls
Symbol
Meaning
Symbol
Meaning
On-off switch, without electrical
isolation
On-off button, without electrical
isolation
