9.3 Current and power requirements and power supply units
144
9.3 Current and power requirements and power supply units
9.3.1 Current and power requirements of the system components
See the note in "Applicability of technical specifications (Page 141)".
Maximum current values
Component
Voltage
+3.3 V
+5 V
+12 V1
+12 V2
-12 V
5 Vaux
Motherboard Core i3 / i5 / i7 / i9 CPU with cooling
1
0.7 A
4.5 A
1.3 A
6.0 A
0 A
0.5 A
SSD SATA (typical)
0.8 A
Hard disk drive
1
SATA (typical values)
0.6 A
0.3 A
Hard disk drive
1
SATA type Enterprise (typical
values)
0.5 A
0.7 A
M.2 NVMe SSD
2.24 A
Internal fan
0.25 A
Graphics card: NVIDIA T400
3.1 A
1.7 A
Graphics card: NVIDIA RTX A2000
0.4 A
5.7 A
Graphics card: NVIDIA RTX A4000
5
0.4 A
11.7 A
Graphics card: NVIDIA RTX A5000
5
0.4 A
17.7 A
Individual currents, max. permissible,
Power supply unit 550 W
25 A
2
22 A
2
26 A
15 A
0.1 A
2.0 A
3
Individual currents, max. permissible,
Power supply unit 700 W (2 modules, each 700 W,
redundant)
20 A
2
20 A
2
58.3 A
0.5 A
3.0 A
Total power, permissible,
Power supply unit 550 W or
Power supply unit 700 W (2 modules, each 700 W,
redundant),
(at 40 °C ambient temperature)
300 W
Individual currents, max. permissible,
Power supply unit 850 W
20 A
2
35 A
2
70 A
0.3 A
3.0 A
Total power, permissible,
Power supply unit 850 W,
(at 40 °C ambient temperature)
300 to 460 W
4
Efficiency of the power supply unit 550 W
1
Ca. 88% (230 V; AC) / ca. 88% (120 V; AC)
Efficiency of the power supply unit 850 W
1
Ca. 87% (230 V; AC) / ca. 87% (120 V; AC)
Efficiency of the power supply unit 700 W (2
modules, each 700 W, redundant)
1
Ca. 89% (230 V; AC) / ca. 87% (120 V; AC)
1
Depends on the selected device configuration
2
The total power of the +5 V and +3.3 V voltage may be max. 150 W for the power supply unit 550 W, max. 130 W for
the redundant power supply unit 700 W and max. 200 W for the power supply unit 850 W.
3
2.5 A for 10 seconds
4
If the power is drawn from an actively cooled expansion card (for example: High-end graphics card) that emits its waste
heat directly into the ambient air and not into the interior of the device. The requirements of the expansion card for the
temperature of the intake air (inside the device) must be observed.
5
Operation only permissible in conjunction with power supply unit 850 W
