Operating the device
6.4 Onboard RAID system
81
12.Select "Create Volume".
The following window now displays the details of the RAID system (RAID Volume) that has
just been set up.
The onboard RAID system is set up.
13.To exit the firmware settings, press the <F4> button (Save & Exit) and confirm the
subsequent dialog with <Y>.
Configuring onboard RAID system with "Intel® Optane™ Memory and Storage Management"
1. Select "Start" > "Intel® Optane™ Memory and Storage Management".
2. Select the "Manage" tab.
You can find information on configuring a RAID system with "Intel® Optane™ Memory and
Storage Management" in the documentation or in the help for the software.
6.4.3.2 Monitoring the onboard RAID system with "Intel® Optane™ Memory and Storage
Management"
Use the Intel® Optane™ Memory and Storage Management software to monitor the onboard
RAID system.
You can find information on monitoring a RAID system with "Intel® Optane™ Memory and
Storage Management" in the documentation or help for the software.
Open "Intel® Optane™ Memory and Storage Management"
1. Select Start > Intel® Optane™ Memory and Storage Management.
Display status of the onboard RAID system (faulty drive)
1. Select the "Manage" tab.
In the right area of the window, a list of the drives mounted in the onboard RAID is
displayed under "Storage System View".
Note
Different numbering of the drives
Note the different numbering of the drives for "Intel® Optane
™ Memory and Storage
ice. See important note under "
Display of a defective drive of an
onboard RAID system (Page 78)".
2. Right-click on a drive from the list or on "Volume".
Status displays are shown for functions and components of the drives or the onboard RAID
system.
Workstation SIMATIC IPC RW-545A
Operating Instructions, 08/2023, A5E52943278-AA
