3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
144 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
No.
Designation
Designation
Information
36
OP - Button 4
OP OPD
37 Reserved
38
Reserved
39 Reserved
40
DPV1/RS-232 interface
(acyclic data)
Acyclic receive data - Bit 0.0
BU0 BU1 BU2(+)
41
Acyclic receive data - Bit 0.1
BU0 BU1 BU2(+)
42
Acyclic receive data - Bit 0.2
BU0 BU1 BU2(+)
43
Acyclic receive data - Bit 0.3
BU0 BU1 BU2(+)
44
Acyclic receive data - Bit 0.4
BU0 BU1 BU2(+)
45
Acyclic receive data - Bit 0.5
BU0 BU1 BU2(+)
46
Acyclic receive data - Bit 0.6
BU0 BU1 BU2(+)
47
Acyclic receive data - Bit 0.7
BU0 BU1 BU2(+)
48
Acyclic receive data - Bit 1.0
BU0 BU1 BU2(+)
49
Acyclic receive data - Bit 1.1
BU0 BU1 BU2(+)
50
Acyclic receive data - Bit 1.2
BU0 BU1 BU2(+)
51
Acyclic receive data - Bit 1.3
BU0 BU1 BU2(+)
52
Acyclic receive data - Bit 1.4
BU0 BU1 BU2(+)
53
Acyclic receive data - Bit 1.5
BU0 BU1 BU2(+)
54
Acyclic receive data - Bit 1.6
BU0 BU1 BU2(+)
55
Acyclic receive data - Bit 1.7
BU0 BU1 BU2(+)
56 PLC/PCS interface PLC [DPV0] (cyclic
data)
Cyclic receive data - Bit 0.0 BU0 BU1 BU2(+)
57
Cyclic receive data - Bit 0.1
BU0 BU1 BU2(+)
58
Cyclic receive data - Bit 0.2
BU0 BU1 BU2(+)
59
Cyclic receive data - Bit 0.3
BU0 BU1 BU2(+)
60
Cyclic receive data - Bit 0.4
BU0 BU1 BU2(+)
61
Cyclic receive data - Bit 0.5
BU0 BU1 BU2(+)
62 Cyclic receive data - Bit 0.6 BU0 BU1 BU2(+)
63
Cyclic receive data - Bit 0.7
BU0 BU1 BU2(+)
64
Cyclic receive data - Bit 1.0
BU0 BU1 BU2(+)
65
Cyclic receive data - Bit 1.1
BU0 BU1 BU2(+)
66
Cyclic receive data - Bit 1.2
BU0 BU1 BU2(+)
67
Cyclic receive data - Bit 1.3
BU0 BU1 BU2(+)
68
Cyclic receive data - Bit 1.4
BU0 BU1 BU2(+)
69
Cyclic receive data - Bit 1.5
BU0 BU1 BU2(+)
70
Cyclic receive data - Bit 1.6
BU0 BU1 BU2(+)
71
Cyclic receive data - Bit 1.7
BU0 BU1 BU2(+)
72
Enabled control command
Enabled control command ON<<
Dependent on the control
function
73
Enabled control command ON<
74
Enabled control command - OFF
75
Enabled control command ON>
76
Enabled control command ON>>
77
Reserved
