Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
145
No.
Designation
Designation
Information
78
Reserved
79 Reserved
80
Contactor controls
Contactor controls 1 QE1
Dependent on the control
function
81 Contactor controls 2 QE2
82
Contactor controls 3 QE3
83
Contactor controls 4 QE4
84
Contactor controls 5 QE5
85
Reserved
86
Reserved
87
Reserved
88
Lamp controls
Display - QLE<<(ON<<)
Dependent on the control
function
89
Display - QLE<(ON<)
90
Indication - QLA (OFF)
91
Display - QLE>(ON>)
92
Display - QLE>>(ON>>)
93
Display - QLS (fault)
BU0 BU1 BU2(+)
94
Reserved
95
Reserved
96
Status information - General
Status - General fault
BU0 BU1 BU2(+)
97
Status - General warning
BU0 BU1 BU2(+)
98 Status - Device BU0 BU1 BU2(+)
99
Status - Bus
BU0 BU1 BU2(+)
100
Status - PLC/PCS
BU0 BU1 BU2(+)
101
Status - Current flowing
IM UM(+)
102
Reserved
103
Reserved
104 Status information - Receive Status - ON<< Dependent on the control
function
105
Status - ON<
106
Status - Off
107
Status - ON>
108
Status - ON>>
109
Status - Start active
BU0 BU1 BU2(+)
110 Status - Interlocking time active All reversing starters and
positioners
111 Status - Change-over pause active Star-delta starter,
Dahlander starter,
pole-changing starter
112
Status - Runs in open direction
Dependent on the control
function
113
Status - Runs in close direction
114
Status - FC
115
Status - FO
116
Status - TC
117
Status - TO
