Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
206 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Node ID
Data type
Description
GG3
GG3 GP
166
Boolean
Event - Trip level P>
✓
—
167 Boolean Event - Trip level P< ✓ —
168
Boolean
Event - Trip level cos phi<
✓
—
169 Boolean Event - Trip level U< ✓ —
170
Boolean
Event - AM1 trip level 0/4-20mA>
✓
—
171
Boolean
Event - AM1 trip level 0/4-20mA<
✓
—
172
Boolean
Event - Stalled rotor
✓
✓
173
Boolean
Event - Warning Internal ground fault
✓
✓
175
Boolean
Event - No start possible
✓
✓
176
Boolean
Event - No. of starts>
✓
✓
177
Boolean
Event - Just one start possible
✓
✓
178
Boolean
Event - Motor operating hours >
✓
✓
179
Boolean
Event - Motor stop time >
✓
✓
180
Boolean
Event - Limit monitor 1
✓
✓
181
Boolean
Event - Limit monitor 2
✓
✓
182
Boolean
Event - Limit monitor 3
✓
✓
183
Boolean
Event - Limit monitor 4
✓
✓
184
Boolean
Event - External fault 1
✓
✓
185
Boolean
Event - External fault 2
✓
✓
186
Boolean
Event - External fault 3
✓
✓
187 Boolean Event - External fault 4 ✓ ✓
188
Boolean
Event - External fault 5
✓
✓
189
Boolean
Event - External fault 6
✓
✓
191
Boolean
Event - Module-FW update active
✓
✓
192
Boolean
Event - AM1 open circuit
✓
—
193
Boolean
Event - DM-F safety-related tripping
✓
—
194 Boolean Event - Monitoring interval for mandatory testing -
test required
✓ —
195
Boolean
Event - Time set (NTP)
✓
✓
196
-
-
197
Boolean
Event - Time synchronized (NTP)
✓
✓
198
Boolean
Event - DM-F LOCAL o.k.
✓
—
199
Boolean
Event - DM-F PROFIsafe active
✓
—
200
Boolean
Event - Configured operation panel missing
✓
✓
201
Boolean
Event - Module not supported
✓
✓
202
Boolean
Event - No module voltage
✓
✓
204
Boolean
Event - Memory module read in
✓
✓
205
Boolean
Event - Memory module programmed
✓
✓
206
Boolean
Event - Memory module cleared
✓
✓
208
Boolean
Event - Initialization module read in
✓
✓
209
Boolean
Event - Initialization module programmed
✓
✓
210
Boolean
Event - Initialization module cleared
✓
✓

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
