Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
210 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Node ID
Data type
Description
GG3
GG3 GP
349
Boolean
Trip - Test shutdown
✓
✓
350 Boolean Trip - Safety-related tripping ✓ ✓
351
Boolean
Trip - Wiring
✓
✓
352 Boolean Trip - Cross circuit ✓ ✓
356
Boolean
Trip - TM2 trip level T>
✓
✓
357
Boolean
Trip - TM2 sensor fault
✓
✓
358
Boolean
Trip - TM2 out of range
✓
✓
364
Boolean
Trip - AM2 trip level 0/4-20mA>
✓
✓
365
Boolean
Trip - AM2 trip level 0/4-20mA<
✓
✓
372
Boolean
Trip - AM2 open circuit
✓
✓
Diagnostic warnings
388
Boolean
Warning - TM2 warning level T>
✓
✓
390
Boolean
Warning - TM2 sensor fault
✓
✓
391
Boolean
Warning - TM2 out of range
✓
✓
396
Boolean
Warning - AM2 warning level 0/4-20mA>
✓
✓
397
Boolean
Warning - AM2 warning level 0/4-20mA<
✓
✓
404
Boolean
Warning - AM2 open circuit
✓
✓
Diagnostic events
420
Boolean
Event - TM2 warning level T>
✓
✓
421
Boolean
Event - TM2 trip level T>
✓
✓
422 Boolean Event - TM2 sensor fault ✓ ✓
423
Boolean
Event - TM2 out of range
✓
✓
428
Boolean
Event - AM2 warning level 0/4-20mA>
✓
✓
429
Boolean
Event - AM2 warning level 0/4-20mA<
✓
✓
430
Boolean
Event - AM2 trip level 0/4-20mA>
✓
✓
431
Boolean
Event - AM2 trip level 0/4-20mA<
✓
✓
432 Boolean Event - Limit monitor 5 ✓ ✓
433
Boolean
Event - Limit monitor 6
✓
✓
444
Boolean
Event - AM2 open circuit
✓
✓
Acyclic send
450
Boolean
Acyclic send data 0.0
✓
✓
451
Boolean
Acyclic send data 0.1
✓
✓
452
Boolean
Acyclic send data 0.2
✓
✓
453
Boolean
Acyclic send data 0.3
✓
✓
454
Boolean
Acyclic send data 0.4
✓
✓
455
Boolean
Acyclic send data 0.5
✓
✓
456
Boolean
Acyclic send data 0.6
✓
✓
457
Boolean
Acyclic send data 0.7
✓
✓
458
Boolean
Acyclic send data 1.0
✓
✓
459
Boolean
Acyclic send data 1.1
✓
✓
460
Boolean
Acyclic send data 1.2
✓
✓
461
Boolean
Acyclic send data 1.3
✓
✓
