Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
209
Node ID
Data type
Description
GG3
GG3 GP
294
Boolean
Trip - Feedback on
✓
✓
295 Boolean Trip - Feedback off ✓ ✓
296
Boolean
Trip - Stalled positioner
✓
✓
297 Boolean Trip - Double 0 ✓ ✓
298
Boolean
Trip - Double 1
✓
✓
299
Boolean
Trip - End position
✓
✓
300
Boolean
Trip - Antivalence
✓
✓
301
Boolean
Trip - Test position feedback (TPF)
✓
✓
302
Boolean
Trip - Power failure (UVO)
✓
✓
303
Boolean
Trip - Operational Protection OFF (OPO)
✓
✓
309
Boolean
Trip - Unbalance
✓
✓
310
Boolean
Trip - Overload
✓
✓
311
Boolean
Trip - Overload + loss of phase
✓
✓
312
Boolean
Trip - Internal ground fault
✓
✓
313
Boolean
Trip - External ground fault
✓
✓
315
Boolean
Trip - Thermistor trip level
✓
✓
316
Boolean
Trip - Thermistor short circuit
✓
✓
317
Boolean
Trip - Thermistor open circuit
✓
✓
319
Boolean
Trip - TM1 trip level T>
✓
✓
320
Boolean
Trip - TM1 sensor fault
✓
✓
321 Boolean Trip - TM1 out of range ✓ ✓
322
Boolean
Trip - EM Open Circuit
✓
✓
323
Boolean
Trip - EM Short Circuit
✓
✓
324
Boolean
Trip - Trip level I>
✓
✓
325
Boolean
Trip - Trip level I<
✓
✓
326
Boolean
Trip - Trip level P>
✓
✓
327 Boolean Trip - Trip level P< ✓ ✓
328
Boolean
Trip - Trip level cos phi<
✓
✓
329
Boolean
Trip - Trip level U<
✓
✓
330
Boolean
Trip - AM1 trip level 0/4-20mA>
✓
✓
331
Boolean
Trip - AM1 trip level 0/4-20mA<
✓
✓
332
Boolean
Trip - Stalled rotor
✓
✓
336
Boolean
Trip - No. of starts >
✓
✓
340
Boolean
Trip - External fault 1
✓
✓
341
Boolean
Trip - External fault 2
✓
✓
342
Boolean
Trip - External fault 3
✓
✓
343
Boolean
Trip - External fault 4
✓
✓
344
Boolean
Trip - External fault 5
✓
✓
345
Boolean
Trip - External fault 6
✓
✓
346
Boolean
Trip - Dry running pump
✓
—
347
Boolean
Trip - Dry-running protection error
✓
—
348
Boolean
Trip - AM1 open circuit
✓
✓
