Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
208 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Table 3- 46 Node IDs (2)
Node ID
Data type
Description
GG3
GG3 GP
Diagnostic warnings (2)
246 Boolean Warning - TM1 warning level T> ✓ ✓
248
Boolean
Warning - TM1 sensor fault
✓
✓
249 Boolean Warning - TM1 out of range ✓ ✓
250
Boolean
Warning - EM Open Circuit
✓
✓
251
Boolean
Warning - EM Short Circuit
✓
✓
252
Boolean
Warning - Warning level I>
✓
✓
253
Boolean
Warning - Warning level I<
✓
✓
254
Boolean
Warning - Warning level P>
✓
✓
255
Boolean
Warning - Warning level P<
✓
✓
256
Boolean
Warning - Warning level cos phi<
✓
✓
257
Boolean
Warning - Warning level U<
✓
✓
258
Boolean
Warning - AM1 warning level 0/4-20mA>
✓
✓
259
Boolean
Warning - AM1 warning level 0/4-20mA<
✓
✓
260
Boolean
Warning - Stalled rotor
✓
✓
263
Boolean
Warning - No start possible
✓
✓
264
Boolean
Warning - No. of starts>
✓
✓
265
Boolean
Warning - Just one start possible
✓
✓
266
Boolean
Warning - Motor operating hours >
✓
✓
267
Boolean
Warning - Motor stop time >
✓
✓
268 Boolean Warning - External fault 1 ✓ ✓
269
Boolean
Warning - External fault 2
✓
✓
270
Boolean
Warning - External fault 3
✓
✓
271
Boolean
Warning - External fault 4
✓
✓
272
Boolean
Warning - External fault 5
✓
✓
273
Boolean
Warning - External fault 6
✓
✓
276 Boolean Warning - AM1 open circuit ✓ ✓
277
Boolean
Warning - Safety-related tripping
✓
✓
278
Boolean
Warning - Test required
✓
✓
282
Boolean
Warning - Feedback circuit
✓
✓
283
Boolean
Warning - Simultaneity
✓
✓
Diagnostic trips
284
Boolean
Trip - Hardware fault basic unit
✓
✓
285
Boolean
Trip - Module fault
✓
✓
286
Boolean
Trip - Temporary components
✓
✓
287
Boolean
Trip - Configuration fault
✓
✓
288
Boolean
Trip - Parameterization
✓
✓
289
Boolean
Trip - Bus
✓
✓
290
Boolean
Trip - PLC/DCS
✓
✓
292
Boolean
Trip - Execution on-command
✓
✓
293
Boolean
Trip - Execution stop command
✓
✓
