Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
215
No.
Designation
Designation
Information
118
Status - Cold start (TPF)
119 Status - OPO
120
Status - Remote mode
121 Status information - Protection Status - Emergency start executed IM UM(+)
122
Status - Cooling down period active
IM UM(+)
123
Status - Pause time active
IM UM(+)
124
Status information - Miscellaneous
Status - Device test active
125
Status - Phase sequence 1-2-3
UM(+)
126
Status - Phase sequence 3-2-1
UM(+)
127
Status - DM-F enabling circuit
DM-F
128
Events - Protection
Event - Overload operation
IM UM(+)
129
Event - Unbalance
IM UM(+)
130
Event - Overload
IM UM(+)
131
Event - overload + phase failure
IM UM(+)
132
Event - Internal ground fault
IM UM(+)
133
Event - External ground fault
EM
134
Event - Warning ext. ground fault
EM
135
Event - Thermistor overload
Th
136
Event - Thermistor short-circuit
Th
137
Event - Thermistor open circuit
Th
138 Event - TM1 warning T> TM1
139
Event - TM1 trip T>
TM1
140
Event - TM1 sensor fault
TM
141
Event - TM1 out of range
TM
142
Event - EM+ open circuit
EM+
143
Event - EM+ short-circuit
EM+
144 Events - Level monitoring Event - Warning I> IM UM(+)
145
Event - Warning I<
IM UM(+)
146
Event - Warning P>
UM(+)
147
Event - Warning P<
UM(+)
148
Event - Warning cos phi<
UM(+)
149
Event - Warning U<
UM(+)
150
Event - Warning 0/4 - 20mA>
AM1
151
Event - Warning 0/4 - 20mA<
AM1
152
Event - Trip I>
IM UM(+)
153
Event - Trip I<
IM UM(+)
154
Event - Trip P>
UM(+)
155
Event - Trip P<
UM(+)
156
Event - Trip cos phi<
UM(+)
157
Event - Trip U<
UM(+)
158
Event - Trip 0/4-20 mA>
AM1
159
Event - Trip 0/4-20 mA<
AM1

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
