Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
216 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
No.
Designation
Designation
Information
160
Event - Stalled rotor
IM UM(+)
161 Events - Protection Event - Warning internal ground fault
162
Reserved
163 Event - No start permitted
164
Events - Level monitoring
Event - No. of starts >
165
Event - Just one start possible
166
Event - Motor operating hours >
167
Event - Motor stop time >
168
Event - Limit 1
169
Event - Limit 2
170
Event - Limit 3
171
Event - Limit 4
172
Events - Miscellaneous
Event - External fault 1
173
Event - External fault 2
174
Event - External fault 3
175
Event - External fault 4
176
Event - External fault 5
177
Event - External fault 6
178
Reserved
179
Event - AM2 open circuit
AM2
180 Event - AM1 open circuit AM1, AM2
181
Event - DM-F safety-related tripping
DM-F
182
Event - DM-F - Test requirement
DM-F
183
Reserved
184
Reserved
185
Reserved
186 Events - Miscellaneous Event - DM-FL safety o.k DM-FL
187
Event - DM-FP PROFIsafe active
DM-FP
188
Events - System interface
Event - Configured operator panel missing
189
Reserved
190
Warnings - Miscellaneous
Warning - DM-F feedback circuit
DM-F
191
Warning - DM-FL simultaneity
DM-FL
192
Faults - General
Fault - HW fault basic unit
193
Fault - Module fault (e.g. IM, DM)
194 Fault - Temporary components (e.g. memory
module)
195
Fault - Configuration error
196
Fault - Parameterization
197
Fault - Bus
198
Fault - PLC/PCS
199
Fault - Dry running pump
UM+ TL
200
Faults - Control
Fault - Execution Time ON
Not for overload

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
