Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
246 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.
Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Information
28.0
Byte parameters (28)
28.0 Internal ground fault - Delay Byte 0 .. 255 100
ms
5
IM UM(+)
29.0 Overload protection - Class Byte 5, 7, 10 ..
35, 40
10
30.0 Motor protection - Delay with
overload operation
Byte 0 - 255 100
ms
5
IM UM(+)
31.0 Motor protection - unbalance
protection level
Byte 0 - 100 1 % 40
IM UM(+)
32.0 Motor protection - Unbalance
protection - Delay in the event
of unbalance
Byte 0 - 255 100
ms
5
IM UM(+)
33.0 Interlocking time Byte 0 - 255 1 s 0
34.0 FB time Byte 0 - 255 100
ms
5 0 = disabled
35.0 Trip level I> Byte 0 - 255 4 %
/ I
s
0
IM UM(+)
36.0 Warning level I> Byte 0 - 255 4 %
/ Is
0
IM UM(+)
37.0 Trip level I< Byte 0 - 255 4 %
/ Is
0
IM UM(+)
38.0 Warning level I< Byte 0 - 255 4 %
/ Is
0
IM UM(+)
39.0 Stalled rotor level Byte 0 - 255 4 %
/ Is
0
IM UM(+)
40.0 Trip delay I> Byte 0 - 255 100
ms
5
IM UM(+)
41.0 Warning delay I> Byte 0 - 255 100
ms
5
IM UM(+)
42.0 Trip delay I< Byte 0 - 255 100
ms
5
IM UM(+)
43.0 Warning delay I< Byte 0 - 255 100
ms
5
IM UM(+)
44.0 Blocking delay Byte 0 - 255 100
ms
5
IM UM(+)
45.0 Monitoring the number of starts
- Permissible starts
Byte 1 - 255 1
46.0
Reserved
Byte
0
47.0 EM+
2)
- delay Byte 0 - 255 100
ms
0
