Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
256 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
28.0
Bit[4] - Parameters (25)
28.0 TM1 - sensor type Bit[3] +
Bit
000B to 1
00B
000B 000B = PT100
001B = PT100
010B = KTY83
011B = KTY84
100B = NTC
TM1
28.4 OPD language Bit[4] 0 - 7 1 0 = English
1 = German
2 = French
3 = Polish
4 = Spanish
5 = Portuguese
6 = Italian
7 = Finnish
29.0 External fault 5 - Reset also
by
Bit[4] 0 - 1111B 0101B Bit[0] = Panel reset
Bit[1] = Auto-reset
Bit[2] = Remote
reset
Bit[3] = OFF
command reset
29.4 External fault 6 - Reset also
by
Bit[4] 0 - 1111B 0101B
30.0
OPD - Contrast (bit 0 to 3)
Bit[4]
0 - 255 1 % 50
30.4
OPD - Contrast (bit 4 to 7)
Bit[4]
31.0 OPD - Profile (bit 0 to 3) Bit[4] 0 - 26 0
31.4
OPD - Profile (bit 4 to 7)
Bit[4]
32.0 Truth table 7 type 2I/1O Bit[4] 0 - 1111B 0
32.4
Truth table 8 type 2I/1O
Bit[4]
0 - 1111B
0
33.0 I
s
1 conversion factor -
Denominator
Bit[4] 0 - 15 0
33.4 I
s
2 conversion factor -
Denominator
Bit[4] 0 - 15 0
34.0
Hysteresis P - Cos phi - U
Bit[4]
0 - 15
5
1 %
UM(+)
34.4
Hysteresis 0/4-20 mA
Bit[4]
0 - 15
5
1 %
AM1 AM2
35.0
Hysteresis free limits
Bit[4]
0 - 15
5
1 %
35.4 OPD - Lighting Bit[4] 0 - 4 2 0 = Off
1 = 3 s
2 = 10 s
3 = 1 min
4 = 5 min
36.0
Byte parameters (29)
36.0
Reserved
Byte
0
37.0 EM - Delay Byte 0 - 255 100 ms 5
EM
38.0 Trip level cos phi< Byte 0 - 100 1 % 0
UM(+)
39.0 Warning level cos phi< Byte 0 - 100 1 % 0
UM(+)
