Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
257
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
40.0 Trip level U< Byte 0 - 255 8 V 0
UM(+)
41.0 Warning level U< Byte 0 - 255 8 V 0
UM(+)
42.0 Trip level 0/4-20 mA> Byte 0 - 255 *128 0
AM1
43.0 Warning level 0/4-20 mA> Byte 0 - 255 *128 0
AM1
44.0 Trip level 0/4-20 mA< Byte 0 - 255 *128 0
AM1
45.0 Warning level 0/4-20 mA< Byte 0 - 255 *128 0
AM1
46.0 Trip delay P> Byte 0 - 255 100 ms 5
UM(+)
47.0 Warning delay P> Byte 0 - 255 100 ms 5
UM(+)
48.0 Trip delay P< Byte 0 - 255 100 ms 5
UM(+)
49.0 Warning delay P< Byte 0 - 255 100 ms 5
UM(+)
50.0 Trip delay cos phi< Byte 0 - 255 100 ms 5
UM(+)
51.0 Warning delay cos phi< Byte 0 - 255 100 ms 5
UM(+)
52.0 Trip delay U< Byte 0 - 255 100 ms 5
UM(+)
53.0 Warning delay U< Byte 0 - 255 100 ms 5
UM(+)
54.0 Trip delay 0/4-20 mA> Byte 0 - 255 100 ms 5
AM1
55.0 Warning delay 0/4-20 mA> Byte 0 - 255 100 ms 5
AM1
56.0 Trip delay 0/4-20 mA< Byte 0 - 255 100 ms 5
AM1
57.0 Warning delay 0/4-20 mA< Byte 0 - 255 100 ms 5
AM1
58.0 Delay limit 1 Byte 0 - 255 100 ms 5
59.0 Delay limit 2 Byte 0 - 255 100 ms 5
60.0 Delay limit 3 Byte 0 - 255 100 ms 5
61.0 Delay limit 4 Byte 0 - 255 100 ms 5
62.0 TM - Hysteresis Byte 0 - 255 1 K 5
TM1 TM2
63.0 Max. star time Byte 0 - 255 1 s 20 Star-delta starter
64.0 UVO time Byte 0 - 255 100 ms 0
65.0 Staggering time Byte 0 - 255 1 s 0
66.0 Analog value recording -
Sampling rate
Byte 0 - 20 5% 0
67.0 Calculator 2, Denominator 1 Byte 0 - 255 0
68.0 Calculator 2, Numerator 2 Byte 0 - 255 0
69.0 Calculator 1, Denominator Byte 0 - 255 0
70.0 Truth table 4 type 3I/1O Byte 0 -
1111111
1B
0
71.0 Truth table 5 type 3I/1O Byte 0 -
1111111
1B
0
