Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
258 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
72.0 Truth table 6 type 3I/1O Byte 0 -
1111111
1B
0
73.0 Calculator 2, Numerator 1 Byte -128 -
127
0
74.0 Calculator 2, Denominator 2 Byte -128 -
127
0
75.0 DM-F - Test requirement
level
Byte 0 - 255 1 week 0
76.0
Word parameters (33)
76.0 Analog module - Start value
output
Word 0 - 65535 0 Value for 0/4mA
AM1
78.0 Analog Module - End value
output
Word 0 - 65535 27648 Value for 20mA
AM1
80.0 TM1 - Trip level T> Word 0 - 65535 1 K 0
TM1
82.0 TM1 - Warning level T> Word 0 - 65535 1 K 0
TM1
84.0 Limit monitor 1 - Limit Word 0 - 65535 0
86.0 Limit monitor 2 - Limit Word 0 - 65535 0
88.0 Limit monitor 3 - Limit Word 0 - 65535 0
90.0 Limit monitor 4 - Limit Word 0 - 65535 0
92.0 Timer 3 - Limit Word 0 - 65535 100 ms 0
94.0 Timer 4 - Limit Word 0 - 65535 100 ms 0
96.0 Counter 3 - Limit Word 0 - 65535 0
98.0 Counter 4 - Limit Word 0 - 65535 0
100.0 Change-over pause Word 0 - 65535 10 ms 0
102.0 Analog value recording -
Sampling rate
Word 1 - 50000 1 ms 100
104.0 I
s
1 conversion factor -
Numerator
Word 0 - 65535 0
106.0 I
s
2 conversion factor -
Numerator
Word 0 - 65535 0
108.0
D-word parameters (37)
108.0 Motor protection - Set
current I
s
2
D-word
1)
10 mA 0
112.0 Trip level P> D-word 0 -
0xFFFFF
FFF
1 W 0
UM(+)
116.0 Warning level P> D-word 0 -
0xFFFFF
FFF
1 W 0
UM(+)
120.0 Trip level P< D-word 0 -
0xFFFFF
FFF
1 W 0
UM(+)
