Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
259
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
124.0 Warning level P< D-word 0 -
0xFFFFF
FFF
1 W 0
UM(+)
128.0 Truth Table 9 5I/2O type -
Output 1
Bit[32] 0 - 1-1B 0
132.0 Truth Table 9 5I/2O type -
Output 2
Bit[32] 0 - 1-1B 0
136.0 Calculator 2, Offset D-word -
0x800000
00 -
0x7FFFF
FFF
0
140.0 Calculator 1,
Numerator/Offset
D-word 2x -
32768 -
32767
0
1) Value range dependent on current range of the IM/UM and the conversion factor;
bit 31 = 1, i.e. conversion factor is active
