3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
265
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
16.0
Calculator 4 Prio 1
Bit[2]
0, 1, 2
2
0 = L,
1 = M,
2 = H
16.2 Calculator 4 Prio 2 Bit[2] 0, 1, 2 1
16.4 Calculator 4 Priority 3 Bit[2] 0, 1, 2 0
16.6 Reserved
17.0 Internal ground fault+ - Warning
response
Bit[2] 0, 1, 2 0 0 = Disabled
1 = Signaling
2 = Warn
UM+
17.2 TLS - performance Bit[2] 0, 3 0 0 = Disabled
3 = Tripping
UM+
18.2
Reserved
18.4
Reserved
18.6
Reserved
19.0
Reserved
19.2
Reserved
19.4
Reserved
19.6
Reserved
20.0
Reserved
20.2
Reserved
20.4
Reserved
20.6
Reserved
21.0
Reserved
21.2
Reserved
21.4
Reserved
21.6
Reserved
22.0
Part - Bit[4] parameters
22.0
TM2 - sensor type
Bit[3+1]
000B to 100B
000B
Like TM1
TM2
22.4 Internal ground fault+ -
Hysteresis
Bit[4] 0 ... 15 1 % 5 UM+
23.0
Reserved
23.4
Reserved
24.0
Reserved
24.4
Reserved
25.0
Reserved
25.4
Reserved
26.0
Reserved
26.4
Reserved
27.0
Reserved
27.4
Reserved
28.0
Reserved
28.4
Reserved
