3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
266 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
29.0
Reserved
29.4 Reserved
30.0
Part - Byte parameters
30.0 Trip level 0/4-20 mA > Byte 0 - 255 *128 0 AM2
31.0 Warning level 0/4-20 mA > Byte 0 - 255 *128 0 AM2
32.0 Trip level 0/4-20 mA < Byte 0 - 255 *128 0 AM2
33.0 Warning level 0/4-20 mA < Byte 0 - 255 *128 0 AM2
34.0 Trip delay 0/4-20 mA > Byte 0 - 255 100 ms 5 AM2
35.0 Warning delay 0/4-20 mA > Byte 0 - 255 100 ms 5 AM2
36.0 Trip delay 0/4-20 mA < Byte 0 - 255 100 ms 5 AM2
37.0 Warning delay 0/4-20 mA < Byte 0 - 255 100 ms 5 AM2
38.0 Delay limit 5 Byte 0 - 255 100 ms 5
39.0 Delay limit 6 Byte 0 - 255 100 ms 5
40.0
Truth table 10 type 3I/1O
Byte
0 - 11111111B
0
41.0
Truth table 11 type 3I/1O
Byte
0 - 11111111B
0
Part - Byte parameters
42.0 Internal ground fault+ - warning
delay
Byte 0 ... 255 100 ms 1 UM+
43.0 Internal ground fault+ - Trip
level
Word 0 ... 65535 1 mA 0 Value range
dependent on
current range of
the UM+
UM+
44.0 Internal ground fault+ - Warning
level
Word 0 ... 65535 1 mA 0 Value range
dependent on
current range of
the UM+
UM+
45.0 TLS - delay Byte 0 ... 100 100 ms 5 UM+_TL
46.0 TLS - T bridge Byte 0 ... 120 500 ms 0 UM+_TL

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
