3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
267
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
47.0
Reserved
48.0 Reserved
49.0
Reserved
50.0 Reserved
51.0
Reserved
52.0
Reserved
53.0
Reserved
54.0
Reserved
55.0
Reserved
56.0
Reserved
57.0
Reserved
58.0
Reserved
59.0
Reserved
60.0
Part - Word parameters
60.0 AM2 - Start value output Word 0 - 65535 0 Value for 0/4 mA AM2
62.0 AM2 - End value output Word 0 - 65535 27648 Value for 20 mA AM2
64.0 TM2 - Trip level T> Word 0 - 65535 1K 0 TM2
66.0 TM2 - Warning level T> Word 0 - 65535 1K 0 TM2
68.0 Limit level 5 Word 0 - 65535 0
70.0 Limit level 6 Word 0 - 65535 0
72.0 Timer 5 value Word 0 - 65535 100 ms 0
74.0 Timer 6 value Word 0 - 65535 100 ms 0
76.0 Counter 5 value Word 0 - 65535 0
78.0 Counter 6 value Word 0 - 65535 0
80.0 Calculator 3 const 1 Word 0 - 65535 0
82.0 Calculator 3 const 2 Word 0 - 65535 0
84.0 Calculator 3 const 3 Word 0 - 65535 0
86.0 Calculator 3 const 4 Word 0 - 65535 0
88.0 Calculator 4 const 1 Word 0 - 65535 0
90.0 Calculator 4 const 2 Word 0 - 65535 0
92.0 Calculator 4 const 3 Word 0 - 65535 0
94.0 Calculator 4 const 4 Word 0 - 65535 0
96.0 Analog multiplexer const 1 Word 0 - 65535 0
98.0 Analog multiplexer const 2 Word 0 - 65535 0
