Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
268 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
100.0 Analog multiplexer const 3 Word 0 - 65535 0
102.0 Analog multiplexer const 4 Word 0 - 65535 0
104.0 PWM input const Word 0 - 65535 0
106.0 PWM input Min Word 0 - 65535 0
108.0 PWM input Max Word 0 - 65535 0
110.0 PWM duration Word 0 - 65535 100 ms 20
Part - Word parameters
112.0
Reserved
Word
114.0
Reserved
Word
116.0
Reserved
Word
118.0 Reserved Word
120.0
Reserved
Word
122.0 Reserved Word
124.0
Reserved
Word
126.0
Reserved
Word
128.0
Reserved
Word
130.0
Reserved
Word
132.0
Reserved
Word
134.0
Reserved
Word
136.0
Reserved
Word
138.0
Reserved
Word
140.0
Part - D-word parameters
140.0 PE - min. pause time motor D-word 0 - FFFFFFFF 1 ms 0
144.0
Reserved
D-word
148
Part - Float parameters
148.0 ..
168.0
Reserved Float
172.0
Reserved
Float
176.0 TLS threshold Float UM+_TL
